NYP型內環式高粘度轉子泵

NYP型內環式高粘度轉子泵是根據石油、化工、涂料、油脂、醫藥、染料、食品等行業的需求,研制的新型容積式泵,由于該產品可選用不同的材質和其   的結構,因此廣泛應用于不同性質,不同粘度的介質輸送。

NYP型內環式高粘度轉子泵適用介質溫度:-10℃—200℃(NYPO.78和NYP2.3的適用溫度為-10℃—80℃)。

NYP型內環式高粘度轉子泵適用介質粘度:1.0cSt—300,000cSt(NYPO.78和NYP2.3的適用粘度為1.0cSt—10,000cSt)。

NYP型內環式高粘度轉子泵具有以下優點:

(1)輸送液體平穩,無脈動,振動小,噪音低。

(2)有的自吸性能。

(3)正確選用零件材料,可輸送多種有腐蝕性的介質,使用溫度可200℃。

(4)內外轉子轉向相同,磨損小,使用壽命長。

(5)泵的轉速與流量呈線性函數關系,可適當改變轉還來改變泵的流量。

(6)特別適用高粘度稠度介質的輸送。

選擇NYP型內環式高粘度轉子泵的理由:

1、密封維修,換,升級方便:NYP保溫泵系列,軸承腔加大,軸承部分成為一個整體的部件,只需擰下頂絲即可旋下整個密封腔。密封可以從支架的軸承箱部分直接取下。這樣不僅節省了維修的時間,使維修變得容易。

2、齒輪尾部間隙可調:NYP高粘度泵可以根據粘度的需要,通過調節齒輪間隙,達到泵在不同黏度下的工藝要求。整體軸承箱大優勢就是,只需轉動軸承箱即可實現間隙的調整。操作簡單,不需拆卸泵的任何部件。

3、加大軸承腔第三大優勢:寬大的支架腔提供的空間,不需拆泵,即可對填料進行調節。

4、保溫夾套整體鑄造,保溫效果好,零泄漏。

5、整塊材料的鑄造,避免了因振動、強外力等緣故造成對密封、軸承的影響。了泵輸送的穩定性。

6、大流量泵可以實現高壓下工作。

7、強有力的加粗軸了泵輸送的穩定性。

8、部分重要部件可以根據工藝需要換為各種、   、、耐高壓,和自潤滑的材質。

9、多種填料密封,材質、設計,創(chuàng )造了填料密封勝過機械密封的。

NYP型內環式高粘度轉子泵性能參數:

型號通徑mm理論排量
L/100rev
粘度
cSt
轉速
r/min
壓差(MPa)連接形式
0.40.60.81.0
軸功率流量(L/min)
NYP0.78150.782013900.17/9.30.23/9.00.28/8.80.32/8.6G1/2"
6013900.18/9.50.24/9.20.28/9.00.33/8.9
20013900.31/10.40.35/10.20.39/10.00.43/9.9
60013900.39/10.40.44/10.30.48/10.30.52/10.2
20009100.23/6.80.27/6.80.30/6.80.33/6.7
60007200.24/5.40.31/6.10.30/6.80.40/6.8
NYP2.3252.32014000.38/28.40.49/27.5

G1"
6014000.59/29.20.65/28.8

20014000.61/30.00.72/29.6

60014000.92/31.90.96/31.7

20009100.61/19.90.68/19.7

60007200.77/16.320.83/16.2

NYP3.6403.62014500.69/46.70.94/45.91.18/451.44/43.4法蘭
Flange
6014500.81/47.51.09/46.71.37/45.91.57/44.7
20014501.06/49.71.31/49.21.56/48.81.79/47.3
60014501.45/49.91.61/49.61.77/49.31.93/49
20009601.28/34.31.41/33.81.54/33.71.65/33.6
60006401.08/23.01.18/22.91.28/22.91.37/22.8
200005831.22/20.51.24/20.41.25/20.41.38/20.3
600004550.84/16.30.91/16.20.98/16.11.01/16
NYP7.0
NYP7.0A
(原型號:
NYP3
NYP3A)
407.02014501.36/98.11.8/962.0/94.72.4/93螺紋
Thread
6014501.45/991.9/972.2/96.42.6/95
20014501.62/99.82.0/982.3/97.52.7/97
6009601.4/621.6/651.8/442.0/64
20009601.8/672.0/662.3/652.6/65
60006401.5/44.51.7/441.8/442.0/44
200005831.6/40.51.9/402.1/402.2/40
600004551.46/31.51.8/311.9/312.0/31
NYP245024207201.8/1652.3/1612.8/1583.4/155法蘭
Flange
607202.0/1662.6/1643.1/1623.7/158
2006101.9/1432.5/1413.0/1393.5/136
6005412.1/1272.6/1253.0/1243.5/122
20004752.2/1122.6/1112.9/1103.4/109
60003572.0/852.3/842.6/832.9/83
200003031.9/722.2/722.4/722.6/71
600002281.6/541.8/542.0/542.3/54
NYP52
NYP52A
(原型號:
NYP10
NYP10A)
5052207204.3/3625.8/3556.9/3488.1/340螺紋
Thread
607204.7/3646.2/3587.3/3527.5/346
2006104.6/3095.9/3046.9/3008.0/294
6005414.9/2756.0/2716.8/2687.8/264
20004755.0/2435.9/2386.6/2377.6/235
60003574.1/1844.9/1825.3/1816.2/180
200003033.8/1574.6/1565.1/1555.6/155
600002283.1/1193.7/1184.0/1184.5/118
NYP808080206155.2/4716.9/4618.5/45110.0/433法蘭
Flange
606155.5/4747.2/4658.8/45710.5/448
2005445.7/4217.2/4148.6/40810.1/401
6004796.0/3727.3/3678.5/3629.8/356
20004176.5/3267.7/3228.9/31910.1/315
60003055.6/2396.6/2377.5/3268.4/233
200002285.5/1806.4/1796.9/1787.7/177
600001885.5/1496.1/1496.7/1497.2/148
NYP111
NYP111A
(原型號:
NYP30
NYP30A)
80111.4206156.7/6609.2/64711.2/63413.6/622法蘭
Flange
606156.9/6649.4/65211.5/64213.9/631
2005447.1/5899.3/58011.0/57313.2/563
6004797.3/5219.5/51411.1/50813.1/502
20004177.7/4559.7/45011.0/44712.7/442
60003056.9/3358.4/3329.4/33110.6/328
200002286.3/2517.5/2508.2/2499.2/248
600001886.2/2097.1/2087.6/2088.5/207
NYP160100160206008.9/93012.1/91615.3/90217.5/888法蘭
Flange
606009.4/93512.6/92215.8/91019.0/898
20055012.3/86615.3/85918.3/85221.3/845
60048010.2/75412.8/74715.4/74018.0/737
20003559.1/56011.1/55613/55215.1/548
600031910.0/50511.7/50213.5/50015.2/497
NYP220125220204308.8/90211.9/88015.0/85818.0/836法蘭
Flange
604309.0/90912.0/89015.0/87118.0/852
2003558.5/75311.1/73913.7/72616.3/713
6003209.4/68211.8/67114.1/66016.5/649
20002549.1/54411.0/53713.0/53015.1/523
600024410.1/48311.9/47813.6/47315.4/468
200001609.1/34710.5/34511.9/34313.3/341
600001178.4/2569.4/25510.4/25411.4/253
NYP3201253202043013.0/130618.0/127022.0/123526.0/1200法蘭
Flange
6043013.0/131618.5/128522.0/125526.5/1225
20035511.8/109115.5/106819.1/104622.8/1024
60032013.2/98716.5/96819.7/95022.9/932
200028414.2/88117.4/86720.6/85423.8/841
600022213.7/69316.2/68418.7/67521.2/666
2000016813.2/52915.3/52517.3/52219.4/519
6000012512.0/39713.7/39615.3/39516.9/394
NYP6501506502031519.0/192126.0/185733.0/1794
法蘭
Flange
6031520.0/194026.4/188633.2/1832
20028417.9/175624.0/171130.4/1666
60025317.6/157222.7/153428.9/1500
200019615.7/122520.6/120124.5/1176
600016016.0/100819.8/99322.3/978
2000011713.6/74516.5/73819.2/731
6000010015.0/64517.2/64319.5/640
NYP727
(原型號:
NYP50)
1507272031521.5/213529.4/205837.3/1980
法蘭
Flange
6031522.4/215729.8/209037.3/2026
20028019.6/192826.7/187433.5/1820
60024519.6/169625.1/165231.2/1611
200020018.7/139423.3/136328.5/1334
600017019.2/119523.3/117527.9/1155
2000012517.0/88820.1/87823.3/868
6000010016.8/72019.5/71722.3/713
NYP167020016702025038.0/385252.0/369066.0/3529
法蘭
Flange
6025040.0/390054.0/376368.0/3626
20022537.5/353550.0/342462.5/3313
60019537.0/307948.0/299058.6/2900
200016035.0/254744.0/248553.0/2422
600013534.6/217742.0/213850.0/2100
2000011235.0/183041.5/181048.0/1790
600008536.0/140535.7/140040.6/1392
